Quad Mech SERIES 4 mm

(1 customer review)

Price range: 18.00€ through 27.00€ inc DDV (Tax)

Quad Mech SERIES 4.0 mm Alien coils intended for SERIAL battery configuration 8.4 V

Char limit: 500
Product total
Options total
Grand total

Description

  • Optimized for dual coil atomizers with SERIES battery configuration 8.4 V
  • For unregulated devices – mechs
  • For experienced users

Quad Mech SERIES 4 mm Alien coils intended for SERIES battery configuration 8.4 V. are made for atomizers with not so wide post holes with 4 mm inner diameter.

Because of very thin wire they cool down super-fast!

We made Serial Coils with Quad cores, because why not try the limit of possibility.

Because of very thin wire used the Coils are soft upon installation but they harden when heated with dry burn. Install them with care not to deform them.

Disclaimer: Serial Coils are big coils with lots of mass. It means they cool down later as coils for a parallel battery configuration and in my opinion, they are not as good in overall performance. But I know the Serial Mechs are beautiful and fun, and you want to play with them. I get it. 🙂 On Planet Earth the cool down time is not in favor of Serial Mechs, and you get plenty of vapor with regular Coils. But you’re the boss and You’ve been warned. 🙂





Additional information

About the product

2 coils in the package
Core 4 X 31-gauge (0.23 mm) Nichrome N80
Wrap 38-gauge (0.1 mm) Nichrome N80
7 wraps on 4 mm ID
Resistance:
Single coil 0.748 Ω
Dual coil 0.374 Ω

Measurements of the coil leg and the overall width

Legs width: 1.5 mm
Overall width: 8.0 mm

Safety!

DO NOT use with devices with SERIES configuration. DO NOT use batteries with a damaged wrap. Use only good quality Samsung, Sony, LG, Molicel batteries with at least 20 amps discharge ratio. Always obey Ohm's Law. SAFETY FIRST!
